Attribute Extractor

AutoDWG Attribute Extractor, Faster than ever!

AutoDWG Attribute Extractor is for batch extracting of attribute data from AutoCAD attribute blocks without running AutoCAD.

    Key features:

  • Stand-alone application, run without AutoCAD.
  • Batch extract attribute data from numerous files in one go.
  • Output format of TXT, CSV and Excel file are supported.
  • DWG/DXF file versions from R9 to 2015 are supported.

Why do we extract attribute information?

It is useful when:
1. Creating a list of materials that comes to mind immediately.
2. Extracting attribute information into a spreadsheet program such as Excel, to let you calculate valuable attribute data, sort, etc.

Extracting attributes has always been one of the toughest tasks in AutoCAD. But now, following the guide and clicks mouse for several times, you’ll get what you need.


Stand-alone application, run without AutoCAD

This featured Attribute Extractor is stand-alone, it runs completely without Autodesk products.


Batch Process

This application enables you to batch extract attribute data from numerous files in one go.


Three target formats supported

Attribute extractor supports source formats as DWG and DXF, version from R9 to 2015, and target format as TXT, CSV and Excel format.
News Release:

The latest version of this Attribute Extractor 2015 has been released recently.

Discussions:
1. What is a project file?
>>

The project file (*.PAE) which is used to store the extraction definition information. If you have already done this, please select an existing one; otherwise please create a new one.

If you have any question, please leave the message here:

Try or Buy:

Single user license price (USD)
Lifetime license +1 year update
Atttribute Extractor Standard
Try Buy
$198.00
Bulk discount
Atttribute Extractor Server
Try
Please contact us
Stand-alone application - run without AutoCAD Batch extract attribute data from numerous files in one go Output format of TXT, CSV and Excel file are supported DWG/DXF file version from R9 to 2015 is supported Installed and run on a server for multiple users
No

Download & Buy

Payment Method:

Place order

  • Credit card
  • Paypal
  • Bank/Wire Transfer with Invoice - USD Only ($10.00 USD fee)
  • Check/Money Order ($2.50 USD fee)
  • Fax - Credit Card
  • Purchase Order ($10.00 USD fee)



Notice: Our order system is processed by Mycommerce.com



Order by fax
Please order online first, then you’ll get instructions from Mycommerce.com to continue.



Order by phone(24/7 online)
     1-877-353-7297 (toll free in the US and part of Canada)
     1-952-646-5331 (international toll line).

You can call the phone number above (24 hours a day 7 days a week) to place order by phone.



Registration Code
The code will be automatically emailed to you in 5 minutes after the purchase. By entering the unlock code into the same trial version you have already installed, the program will start working as full version, all trial limitations will be removed at once. There is no need to download again if you already have the trial version installed.



CD & EDS
CD is available for the purchase along with the software, it is optional and takes extra fees, and 1 week up to 3 weeks for the delivery especially if you are located outside US. Only one CD can be added in an order. Extended download service (EDS) is a service of MyCommerce.com, it is optional and removable from your order. Please notice CD and EDS download copies still need enter registration code to remove trial limit.



TAX
Purchasing online may not be tax free in your region, applicable sales tax is automatically calculated for product(s) and shipping costs. For tax exemption instructions, please contact us for more information.
Email: info@autodwg.com

How to Use?

Attribute Extractor

AutoDWG Attribute Extractor is for batch extracting of attribute data from AutoCAD attribute blocks without running AutoCAD. Most DWG formats are supported including AutoCAD R9 – 2015.



Steps to do the conversion

Step 1: Please double click the desktop shortcut to open the program, and create or open a attribute extraction project

Attribute-extractor-step1

Step 2: Define the attribute tag to be extracted

Attribute-extractor-step2

To make it easy, you can select attribute tags from an existing template drawing file, click button "Import".

Attribute-extractor-stpe2-template

First select a template drawing file, AutoDWG Attribute Extractor will enumerate all blocks and attribute tags in the drawing. Check the block name and the attribute tags, press OK, all attribute tags you select will be listed in the Wizard.

Step 3: Add DWG/DXF Files to be extracted

Attribute-extractor-step3

Step 4: Specify the output format and file name, then click the “Next” button to extract attribute.

Attribute-extractor-step4

Reference:

System Requirements:

OS:Compatible with XP, Vista, Win7, Win8
RAM: 1024MB or greater, executable program takes 27Mb, loaded with a drawing file will take more RAM depends on the size of drawing file.
HD: 40MB free hard drive spaces to install



Technical Support:

Free technical support is available to all customers, any question please contact: info@autodwg.com.



Update:

You’ll enjoy one year free update service since you buy the software. After expiry, you can continue using the software but no more updates will be available unless you purchase.
